How to Create Facade Shop Drawings for Curtain Walls

Last Updated: October 25, 2026

Table of Contents

• Understanding the Purpose and Scope of Facade Shop Drawings for Curtain Walls
• How Facade Shop Drawings Differ from Design and Construction Drawings
• Key Project Inputs and Design Documents You'll Need
• The Curtain Wall Shop Drawing Process: From Design Intent to Approval
  • Step 1: Establish Coordination Requirements with Structural and Architectural Teams
  • Step 2: Document Mullions, Transoms, Glazing, and Framing Details
  • Step 3: Define Anchors, Brackets, and Slab-Edge Interfaces
  • Step 4: Specify Dimensions, Levels, Tolerances, and Alignment
• Curtain Wall Shop Drawing Details: Elevations, Plans, and Sections
• Using a Facade Shop Drawing Checklist to Prevent Coordination Errors
• Creating Curtain Wall Revit Shop Drawings with Precision and Interoperability
• Submitting Your Shop Drawings for Technical Review and Approval
• Frequently Asked Questions

Understanding the Purpose and Scope of Facade Shop Drawings for Curtain Walls

Facade shop drawings for curtain walls are detailed technical documents that translate architectural design intent into precise fabrication and installation instructions. They bridge the gap between what an architect envisions and what a glazing contractor can actually build.

These drawings serve three critical purposes. First, they verify that the design meets performance requirements: thermal performance, water penetration resistance, air infiltration control, and structural adequacy. Second, they establish exact dimensions, tolerances, and alignment specifications so fabrication happens correctly the first time. Third, they coordinate the building envelope with structural elements, mechanical systems, and adjacent trades to prevent costly on-site conflicts.

Rigorous shop drawing development matters.

The scope of facade shop drawings for curtain walls typically includes:

• Elevation views showing the glazing system layout, mullion spacing, and panel modules
• Plan and section views detailing sightlines, framing depths, and interface conditions
• Material specifications and finishes for all components
• Anchor and bracket details showing how the curtain wall connects to the building structure

How Facade Shop Drawings Differ from Design and Construction Drawings

Design drawings show intent.

An architectural design drawing might show a curtain wall system at 1:100 scale, indicating the general wall type and glazing areas.

Facade shop drawings zoom in to the system level. They specify mullion profiles, transoms, glazing panel dimensions, and the exact sequence of components.

The distinction matters for coordination. When a structural engineer needs to verify that anchors will work, they reference shop drawings, not design drawings.

Key Project Inputs and Design Documents You'll Need

Before creating facade shop drawings for curtain walls, gather these critical inputs from your design and engineering teams:

Architectural design drawings must define the glazing layout, mullion spacing, and aesthetic intent. Include elevation drawings showing panel modules, sightlines, and any curved or non-standard geometry. Specify finishes, colours, and any special requirements like solar control or privacy glazing.

Structural documentation provides anchor locations, load capacities, and movement tolerances.

Building envelope performance criteria set the standards your drawings must meet. In Australia, these are typically defined by the National Construction Code (NCC) and relevant Australian Standards (Building classifications).

System technical documentation from your glazing system supplier, whether Alspec, Capral, Darley, Concept, Rapid, or Criterion, provides the baseline specifications, allowable spans, and assembly procedures. You can explore Alspec system technical support resources to understand the specific requirements of the systems you're detailing.

Project-specific constraints include budget limits, schedule requirements, and any site-specific conditions. Curved window projects, for example, require additional coordination around panel fabrication and installation sequencing.

Without these inputs, shop drawings will be incomplete or require revision, adding delay and cost to the project.

The Curtain Wall Shop Drawing Process: From Design Intent to Approval

Creating facade shop drawings for curtain walls follows a structured workflow that ensures coordination, accuracy, and compliance. The process depends on project complexity and the number of revision cycles required.

Step 1: Establish Coordination Requirements with Structural and Architectural Teams

The first step is clarifying what each discipline needs from the shop drawings and what constraints they impose. Structural compliance for complex facade designs requires early conversation with structural engineers about anchor locations, movement tolerances, and load paths.

Schedule a coordination meeting with the architectural team, structural engineer, mechanical engineer, and key trades. Document:

• Anchor point locations and load capacities
• Building movement data (thermal, seismic, wind-induced)
• Slab-edge conditions and any offsets or irregularities
• Mechanical system penetrations or conflicts

Establish responsibility boundaries. Who approves anchor details? Who verifies thermal performance? Who coordinates with the structural frame? Unclear boundaries create delays when issues arise during review.

Step 2: Document Mullions, Transoms, Glazing, and Framing Details

With coordination requirements confirmed, begin detailing the curtain wall components. This is where precision matters most.

Create detailed drawings showing:

• Mullion profiles: vertical and horizontal members with exact dimensions, material grades, and thermal break specifications
• Transoms: horizontal framing members, spacing, and connection details to mullions
• Glazing panels: dimensions, glass type (tempered, laminated, insulated), and panel module layout
• Framing depth: the distance from the building face to the interior, which affects thermal performance and mechanical coordination

Each detail drawing should show a cross-section at 1:10 or 1:5 scale, with dimensions, tolerances, and material callouts. Show how glazing sits in the frame, where gaskets go, and how thermal breaks are positioned.

Step 3: Define Anchors, Brackets, and Slab-Edge Interfaces

Anchors and brackets connect the curtain wall to the building structure. This is where structural coordination becomes critical.

Document:

• Anchor locations: exact coordinates on each slab edge, with load capacity and movement allowance
• Anchor types: whether you're using cast-in anchors, post-installed anchors, or mechanical connections
• Bracket details: the connection between anchors and the curtain wall frame, showing load paths and fastener specifications
• Slab-edge interfaces: how the curtain wall sits relative to the structural slab, including any thermal breaks or moisture barriers

Show how the anchor allows for building movement, typically ±10-15 mm in each direction. Specify fastener types, sizes, and torque requirements. Call out any special requirements like stainless steel fasteners for corrosion resistance.

SUBMIT →

Step 4: Specify Dimensions, Levels, Tolerances, and Alignment

Precision in dimensions and tolerances prevents fabrication errors and on-site rework.

Include:

• Vertical dimensions: floor-to-floor heights, slab-edge elevations, and mullion centerlines relative to key reference points
• Horizontal dimensions: building grid lines, mullion spacing, and panel module widths
• Tolerances: typical tolerances for curtain wall fabrication are ±3-5 mm for mullion spacing and ±2-3 mm for glass panel dimensions, depending on the system
• Alignment marks: reference points that fabricators and installers use to verify correct positioning

Show cumulative dimensions (the total distance from one end to another) alongside incremental dimensions (individual component sizes). This prevents tolerance stack-up errors where small errors in multiple components combine to create large overall errors.

Curtain Wall Shop Drawing Details: Elevations, Plans, and Sections

Facade shop drawings for curtain walls require three primary view types, each serving a specific purpose.

Elevation views show the glazing system as seen from outside the building.

Plan views show a horizontal slice through the curtain wall, typically at a mullion or transom level.

Section views show a vertical slice perpendicular to the building face.

Each view type should be drawn at a scale appropriate to the detail level, typically 1:50 for general arrangement and 1:10 or 1:5 for detailed connections.

Using a Facade Shop Drawing Checklist to Prevent Coordination Errors

Coordination errors are the most common cause of shop drawing revisions and on-site delays. A systematic checklist catches these issues before submission.

Before submitting shop drawings, verify:

• All dimensions are tied to a common reference point (building grid or slab edge)
• Tolerances are realistic and achievable by fabricators
• Anchor loads don't exceed structural capacity
• Thermal performance calculations match the detailed design
• Water management details prevent ponding or infiltration

Creating Curtain Wall Revit Shop Drawings with Precision and Interoperability

Building Information Modelling (BIM) tools like Revit simplify shop drawing creation and improve coordination across disciplines.

When modelling curtain walls in Revit, establish a parametric system that maintains relationships between components.

Link your model to the structural model and architectural model to catch conflicts early.

Export shop drawings directly with correct scales, dimensions, and annotations. This reduces manual drafting errors and ensures consistency across all drawings.

Interoperability is critical.

Submitting Your Shop Drawings for Technical Review and Approval

Shop drawings must be submitted for technical review before fabrication begins. Understand realistic turnaround times for the approval process so you can plan your project schedule accordingly.

Prepare a submission package that includes:

• Complete set of elevation, plan, and section drawings
• Detailed connection and assembly drawings
• Material specifications and finish schedules
• Thermal and structural calculations
• Water management and air infiltration verification

Submit to the architect, structural engineer, building envelope specialist, and any system suppliers whose products you're specifying.

Expect time for technical review, depending on project complexity and reviewer availability. Reviewers will check for coordination errors, performance compliance, and constructability issues. Common revision requests include:

• Anchor details that need structural verification
• Thermal break positioning that affects performance calculations
• Slab-edge details that conflict with building services
• Tolerance clarifications or adjustments
• Additional details for complex conditions like curved windows or transitions

Incorporate feedback, resubmit, and repeat until all reviewers approve. Approval typically requires sign-off from the architect, structural engineer, and building envelope specialist.

Shop drawings are where design becomes reality.

At BluePrint Facade, we specialise in creating precise facade shop drawings for curtain walls that anticipate coordination issues, verify performance compliance, and provide fabricators with unambiguous instructions. Our experience with systems like Alspec, Capral, and Darley means we understand the technical nuances that prevent costly errors. Get accurate facade and window shop drawings that move your project forward without surprises.
